Torch Adapter Kits

The model of the plasma cutting system must be known to determine the adapter kit required.

Manufacturer Catalog

Power Supply Model Number

AIRCO

/BOC

PCS-43 7-3425

PCS-53, PCS-80, PCS-90 7-3435

CEBORA

50 7-3438

CENTURY

82020

, 82050

7-3476

DAIHEN

SC-60P 7-3432

MRAT-70 7-3437

DAYTON

3W722A

, 5Z031B

7-3476

ESAB

(yellow)

PCM-SMi, 500i, 625i, PCS-43 7-3425

PCS-53, 80, 90 7-3435

ESP-100i 7-3426

PCM-750i, 875, 1000i, 1125 7-3429

Sidewinder 30, 55, 105 7-3434

Powercut

650, 875, 1125, 1250, 1500 7-3462

HARRIS

System 50, 65, 100 7-3439

HOBART

Smoothcut 30, 625 7-3425

Smoothcut 50 (single gas), 100 7-3426

Smoothcut 50 (dual gas) 7-3428

Smoothcut II 35A, 60A, 100A 7-3427

Fab Shop 7-3440

Cybercut 2050

7-3457

HYPERTHERM

Max

40, HT

40 (H/F Start) 7-3430

Max

70, Max

80, Max

100 w/wo Q.D.

Max

, 43

, 40cs

7-3454

powermax

600

, 800

, 900

powermax

1100

7-3455

powermax

1000

, 1250

7-3461

Max

40cs

(wo/ Q.D.) 7-3476

powermax

380

7-3477

INNERLOGIC

SR-45i 7-3451

L TEC

(green)

PCM-31, SMi, 32i/34i, VPi 7-3425

PCM-500i, 625i, PCS-80i

PCM-50A, 70, 80, 52i/54i, 82i/84i 7-3426

ESP-100i, PCM-50, PCM-100 (Single Gas)

PCM-50, PCM-100 (Dual Gas)

PCS-40 7-3430

PCM-750i, 1000i 7-3435

PCM-101 7-3436

Manufacturer Catalog

Power Supply Model Number

LINCOLN

Pro-Cut 60 7-3431

MARQUETTE

12/150 7-3476

MATCO

2020

, 2050

7-3476

MILLER

Plazcut 60/Zipcut 7-3432

Spectrum

250D, 500, 750 7-3433

Spectrum

700, 1000, 1250, PLUS 7-3430

Spectrum

3080

7-3456

Spectrum

650

, 701

, 2050

7-3457

Spectrum

300

7-3476

Spectrum

375

7-3477

MULTIQUIP MQ

PCX50SS 7-3437

NU-TECSYS

Omnicut 375 7-3438

PCA-30/60, 65 7-3441

OTC

Panasonic D-5000, D-7000 7-3437

P-TRON

P-Tron 75, 100 7-3437

POWCON

Starcut 7-3430

SMITH

SPC-30, 20-50, 40-80 7-3442

SNAP-ON

YA-2230

, YA-5550

7-3476

SOLAR

SOL 2020

(118-009, 118-010), SOL 2050

(118-015,118-016) 7-3476

THERMAL DYNAMICS

PAK

3XR, 5XT, 5XR, 6XR, 7XR, 625XR, 750XR 7-3446

PAK

8XR, 10XR, 1000XR, 1250XR, 7-3434

PakMaster

75, 100

PakMaster

50XL/XLP, 75XL/XLP, 100XL/XLP 7-3447

CUTMASTER™ 50, 75, 80XL, 100

PakMaster

25, 38XL, EconoPAK

25 7-3443

Drag-Gun

38, PAK

4Xi, 6Xi

PAK

2XT, Dynapak

110

PakMaster

50 w/ Smart Torch (Q.D.) 7-3445

EconoPAK

50 7-3449

EconoPAK

100 7-3450

PAK

5 7-3444

PAK

10 7-3436

Non-HF Systems.

NOTES: Each Adapter Kit includes connection fitting, electrical connectors and installation instruction sheets for the selected power supply.

CEBORA is a registered trademark of Cebora S.p.A.; DAIHEN is a registered trademark of Daihen Inc.; ESAB and L-TEC are registered trademarks of ESAB AB; HARRIS and LINCOLN are

registered trademarks of Lincoln Electric Co.; HOBART is a registered trademark of Hobart Brothers Co.; HYPERTHERM, Max and powermax are registered trademarks of Hypertherm, Inc.;

MILLER and Spectrum are registered trademarks of Miller Electric Mfg. Co.; MULTIQUIP is a registered trademark of Multiquip, Inc.; NU-TECSYS is a registered trademark of Nu-Tecsys, Inc.;

P-TRON is a registered trademark of P-Tron Plasma/Tech Systems; SMITH is a registered trademark of Smith Equipment Co.; INNERLOGIC is a trademark of Innerlogic; THERMAL DYNAMICS,

PAK, CUTMASTER, PakMaster, EconoPAK, Dynapak and Drag-Gun are registered trademarks of Thermal Dynamics Corp.

The Revolution in Plasma Torches

Has Begun

The Revolution in Plasma Torches

Has Begun

Adapter Kit Selection

Listed below is the Adapter Kit selection charts for

the Machine 1Torch RPT torch.
